DO-4050-3-N



Feature

• This hydraulic hot press is used for hot-press and lamination on no-sewing material, flywire, TPU film and a variety of other materials.

• Double work-bench, highly efficient, allows two-people operation.

• This machine provides upper and lower heating functions. The hot press disc, specially designed with aluminum alloyed, heats quickly, has even temperature distribution, and is rigid and durable.

• Three temperature control systems.

• Alarm of temperature difference.

• Digitalized temperature and timing controls: precise temperature auto control and digital timing auto control to ensure precise timing and guarantee stable quality.

Specification Table

Area of hot disc

Travel

Electric heat power

Max. output

40*50cm

200mm

8.1kw

5Ton

Diameter of cylinder

Max. distance between upper and lower molds

Pressure of pump

Motor

∮100mm

180mm

70kg/cm2

2HP

Temperature

Time

Machine dimensions

Weight

Max.250℃

1sec~99hr

127*104*166cm

625kg
